Quality Testing
  • Production Process
  • Quality Testing
string(1950) "<p align="center">
	<strong><span style="color:#0C86D0;font-size:16px;">Production process description</span></strong>
</p>
<strong><span style="font-size:16px;"></span></strong>
<p>
	<br />
Corrugated conduit are mainly used to compensate for axial displacement, can also compensate for lateral displacement or axial and transverse synthetic displacement, with the ability to compensate for angular displacement. In order to ensure that it play a better application effect, the production process of manufacturing process is essential, the following, to tell you about these two processes.
</p>
<p>
	<br />
<strong><span style="color:#0C86D0;">1. Shaping process</span></strong><br />
Corrugated conduit after forming, due to elastic rebound to the corrugated pipe spacing, wave type and suction meter requirements are different, must be plastic. For the processing of hardened material made of corrugated conduit, generally by hand and mechanical shaping two methods. For the dispersion of hardened material of the corrugated conduit, it will be loaded into the aging fixture aging, so that the corrugated conduit shape, in order to achieve the shaping effect.
</p>
<p>
	<br />
<strong><span style="color:#0C86D0;"> 2. Stabilization process</span></strong><br />
Corrugated conduit in the process, will produce internal stress, so that the shell and the geometric size of instability. The purpose of stabilizing the corrugated conduit is to eliminate stress, stabilize performance, and stabilize the geometry. The stabilization of corrugated conduit includes heat stabilization process and mechanical stabilization process. Under normal circumstances only for heat stability treatment, there are special requirements only when the need for mechanical stability.
</p>
<p>
	<br />
The precise processing of the corrugated conduit, will be able to effectively guarantee its quality, to ensure its good application effect.
</p>
"

Production process description


Corrugated conduit are mainly used to compensate for axial displacement, can also compensate for lateral displacement or axial and transverse synthetic displacement, with the ability to compensate for angular displacement. In order to ensure that it play a better application effect, the production process of manufacturing process is essential, the following, to tell you about these two processes.


1. Shaping process
Corrugated conduit after forming, due to elastic rebound to the corrugated pipe spacing, wave type and suction meter requirements are different, must be plastic. For the processing of hardened material made of corrugated conduit, generally by hand and mechanical shaping two methods. For the dispersion of hardened material of the corrugated conduit, it will be loaded into the aging fixture aging, so that the corrugated conduit shape, in order to achieve the shaping effect.


2. Stabilization process
Corrugated conduit in the process, will produce internal stress, so that the shell and the geometric size of instability. The purpose of stabilizing the corrugated conduit is to eliminate stress, stabilize performance, and stabilize the geometry. The stabilization of corrugated conduit includes heat stabilization process and mechanical stabilization process. Under normal circumstances only for heat stability treatment, there are special requirements only when the need for mechanical stability.


The precise processing of the corrugated conduit, will be able to effectively guarantee its quality, to ensure its good application effect.

string(12758) "Shielding - Electromagnetic compatibility (EMC) technical data
Since the provisions of the electromagnetic compatibility, EMC in the relevant equipment to add more meaning. <br />
<br />
<strong><span style="color:#0C86D0;font-size:14px;"> Equipment is subject to the provisions: </span></strong><br />
<br />
1, the occurrence of electromagnetic interference must be limited, otherwise such equipment can not be produced <br />
<br />
2, if the device has good anti-electromagnetic interference performance, its production is not restricted <br />
<br />
Equipment manufacturers to meet the requirements, increasing demand for the use of shielded connectors, The shielded cable can be connected using a conductive housing connected to a shielded cable. Care should be taken when using the circular connector to carefully introduce the shield of the cable to the shield end of the connector, Therefore, it is preferable to have a 360 degree circular support. If the shield is securely connected to the conductive housing, a good shielding value can be achieved. <br />
<br />
Pure plastic connectors do not have a metal housing. The shield of the cable can not be connected directly. <br />
<br />
Summary: it is important to achieve the integrity of the plug and socket connection between, and make it re-connection between the instrument base. <br />
<br />
<strong><span style="color:#0C86D0;font-size:14px;">Fire 94V level classification </span></strong><br />
<br />
<strong><span style="color:#0C86D0;">Plastic flame retardant grade from HB, V-2, V-1 to V-0 step by step increments: </span></strong><br />
<br />
HB: UL94 standard in the lowest flame retardant rating. For samples of 3 to 13 mm thick, the burning rate is less than 40 mm per minute; for samples less than 3 mm thick, the burning rate is less than 70 mm per minute; or extinguished before the 100 mm mark. <br />
<br />
V-2: After two 10-second burning tests on the sample, the flame is extinguished in 60 seconds. There may be a burning substance that falls off. <br />
<br />
V-1: After two 10-second burning tests on the sample, the flame is extinguished in 60 seconds. Can not have combustion material fall. <br />
<br />
V-0: The flame is extinguished within 30 seconds after two 10-second burning tests on the sample. Can not have combustion mater.<br />
<br />
<strong><span style="color:#0C86D0;font-size:14px;">IP protection level</span></strong> <br />
<table width="100%">
	<tbody>
		<tr>
			<td valign="top">
				<p align="center">
					<strong>The first digit indicates the dustproof index</strong>
				</p>
			</td>
			<td valign="top">
				<p align="center">
					<strong>The second digit indicates the water resistance index</strong><strong> </strong>
				</p>
			</td>
		</tr>
		<tr>
			<td valign="top">
				<p>
					0 means no protection <br />
1 can prevent more than 50mm solid hazards. (Accidental hand contact) <br />
2 can prevent the hazards of the solid more than 12mm. (A finger-sized object) <br />
3 can prevent more than 2.5mm solid hazards. (Thin wire, etc.) <br />
4 can prevent more than 1mm of solid hazards. (Thin wire, etc.) <br />
5 can prevent the hazards of dust.<br />
6 completely prevent the hazards of dust.
				</p>
			</td>
			<td valign="top">
				<p>
					0 means no protection <br />
1 can prevent the vertical fall into the water hazards <br />
2 can prevent vertical direction below 150 angle direct sprinkler harm <br />
3 can prevent vertical direction below 600 angle direct sprinkler harm <br />
4 can prevent the hazards of direct water spray from all directions <br />
5 can prevent the hazards of low pressure water jetting from all directions <br />
6 can prevent the hazards of high pressure water jetting from all directions <br />
7 can prevent the risk of immersion between 15cm~1m <br />
8 can prevent long-term submersion hazards under pressure
				</p>
			</td>
		</tr>
	</tbody>
</table>
<p class="textWrap box">
	<br />
</p>
<p class="textWrap box">
	<strong><span style="color:#0C86D0;font-size:14px;">Stress release VDE0619</span></strong>
</p>
<div class="textWrap box">
	<table width="100%">
		<tbody>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>Cable diameter</strong><strong> </strong><strong>(mm)</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						<strong>Pull (</strong><strong>N)</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						<strong>Torque</strong><strong> (Nm)</strong><strong> </strong>
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						&lt;4
					</p>
				</td>
				<td valign="top">
					<p align="center">
						40
					</p>
				</td>
				<td valign="top">
					<p align="center">
						0.05
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						4-8
					</p>
				</td>
				<td valign="top">
					<p align="center">
						50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						0.1
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						8-11
					</p>
				</td>
				<td valign="top">
					<p align="center">
						60
					</p>
				</td>
				<td valign="top">
					<p align="center">
						0.15
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						11-16
					</p>
				</td>
				<td valign="top">
					<p align="center">
						80
					</p>
				</td>
				<td valign="top">
					<p align="center">
						0.35
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						&gt;16
					</p>
				</td>
				<td valign="top">
					<p align="center">
						100
					</p>
				</td>
				<td valign="top">
					<p align="center">
						0.42
					</p>
				</td>
			</tr>
		</tbody>
	</table>
</div>
<div class="textWrap box">
	<br />
<strong><span style="color:#0C86D0;font-size:14px;">Standard for Torque of Waterproof Joints for Cable</span></strong><br />
	<table width="100%">
		<tbody>
			<tr>
				<td rowspan="2" valign="center">
					<p align="center">
						<strong>Thread size</strong><strong> </strong>
					</p>
				</td>
				<td rowspan="2" valign="center">
					<p align="center">
						<strong>Thread size</strong><strong> </strong>
					</p>
				</td>
				<td colspan="2" valign="top">
					<p align="center">
						<strong>Clamping joints</strong><strong> </strong>
					</p>
				</td>
				<td colspan="2" valign="top">
					<p align="center">
						<strong>Screw nut</strong><strong> </strong>
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>plastic</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						<strong>metal</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						<strong>plastic</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						<strong>metal</strong><strong> </strong>
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>7</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						12
					</p>
				</td>
				<td valign="top">
					<p align="center">
						2.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						6.25
					</p>
				</td>
				<td valign="top">
					<p align="center">
						1.67
					</p>
				</td>
				<td valign="top">
					<p align="center">
						4.17
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>9</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						16
					</p>
				</td>
				<td valign="top">
					<p align="center">
						3.75
					</p>
				</td>
				<td valign="top">
					<p align="center">
						6.25
					</p>
				</td>
				<td valign="top">
					<p align="center">
						2.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						4.17
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>11</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p>
						<br />
					</p>
				</td>
				<td valign="top">
					<p align="center">
						3.75
					</p>
				</td>
				<td valign="top">
					<p align="center">
						6.25
					</p>
				</td>
				<td valign="top">
					<p align="center">
						2.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						4.17
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>13.5</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						20
					</p>
				</td>
				<td valign="top">
					<p align="center">
						3.75
					</p>
				</td>
				<td valign="top">
					<p align="center">
						6.25
					</p>
				</td>
				<td valign="top">
					<p align="center">
						2.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						4.17
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>16</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						25
					</p>
				</td>
				<td valign="top">
					<p align="center">
						5.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						7.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						3.33
					</p>
				</td>
				<td valign="top">
					<p align="center">
						5.00
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>21</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						32
					</p>
				</td>
				<td valign="top">
					<p align="center">
						7.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						10.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						5.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						6.67
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>29</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						40
					</p>
				</td>
				<td valign="top">
					<p align="center">
						7.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						10.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						5.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						6.67
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>36</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						7.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						10.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						5.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						6.67
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>42</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p>
						<br />
					</p>
				</td>
				<td valign="top">
					<p align="center">
						7.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						10.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						5.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						6.67
					</p>
				</td>
			</tr>
			<tr>
				<td valign="top">
					<p align="center">
						<strong>48</strong><strong> </strong>
					</p>
				</td>
				<td valign="top">
					<p align="center">
						63
					</p>
				</td>
				<td valign="top">
					<p align="center">
						7.50
					</p>
				</td>
				<td valign="top">
					<p align="center">
						10.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						5.00
					</p>
				</td>
				<td valign="top">
					<p align="center">
						6.67
					</p>
				</td>
			</tr>
		</tbody>
	</table>
</div>
"
Shielding - Electromagnetic compatibility (EMC) technical data Since the provisions of the electromagnetic compatibility, EMC in the relevant equipment to add more meaning.

Equipment is subject to the provisions:

1, the occurrence of electromagnetic interference must be limited, otherwise such equipment can not be produced

2, if the device has good anti-electromagnetic interference performance, its production is not restricted

Equipment manufacturers to meet the requirements, increasing demand for the use of shielded connectors, The shielded cable can be connected using a conductive housing connected to a shielded cable. Care should be taken when using the circular connector to carefully introduce the shield of the cable to the shield end of the connector, Therefore, it is preferable to have a 360 degree circular support. If the shield is securely connected to the conductive housing, a good shielding value can be achieved.

Pure plastic connectors do not have a metal housing. The shield of the cable can not be connected directly.

Summary: it is important to achieve the integrity of the plug and socket connection between, and make it re-connection between the instrument base.

Fire 94V level classification

Plastic flame retardant grade from HB, V-2, V-1 to V-0 step by step increments:

HB: UL94 standard in the lowest flame retardant rating. For samples of 3 to 13 mm thick, the burning rate is less than 40 mm per minute; for samples less than 3 mm thick, the burning rate is less than 70 mm per minute; or extinguished before the 100 mm mark.

V-2: After two 10-second burning tests on the sample, the flame is extinguished in 60 seconds. There may be a burning substance that falls off.

V-1: After two 10-second burning tests on the sample, the flame is extinguished in 60 seconds. Can not have combustion material fall.

V-0: The flame is extinguished within 30 seconds after two 10-second burning tests on the sample. Can not have combustion mater.

IP protection level

The first digit indicates the dustproof index

The second digit indicates the water resistance index

0 means no protection
1 can prevent more than 50mm solid hazards. (Accidental hand contact)
2 can prevent the hazards of the solid more than 12mm. (A finger-sized object)
3 can prevent more than 2.5mm solid hazards. (Thin wire, etc.)
4 can prevent more than 1mm of solid hazards. (Thin wire, etc.)
5 can prevent the hazards of dust.
6 completely prevent the hazards of dust.

0 means no protection
1 can prevent the vertical fall into the water hazards
2 can prevent vertical direction below 150 angle direct sprinkler harm
3 can prevent vertical direction below 600 angle direct sprinkler harm
4 can prevent the hazards of direct water spray from all directions
5 can prevent the hazards of low pressure water jetting from all directions
6 can prevent the hazards of high pressure water jetting from all directions
7 can prevent the risk of immersion between 15cm~1m
8 can prevent long-term submersion hazards under pressure


Stress release VDE0619

Cable diameter (mm)

Pull (N)

Torque (Nm)

<4

40

0.05

4-8

50

0.1

8-11

60

0.15

11-16

80

0.35

>16

100

0.42


Standard for Torque of Waterproof Joints for Cable

Thread size

Thread size

Clamping joints

Screw nut

plastic

metal

plastic

metal

7

12

2.50

6.25

1.67

4.17

9

16

3.75

6.25

2.50

4.17

11


3.75

6.25

2.50

4.17

13.5

20

3.75

6.25

2.50

4.17

16

25

5.00

7.50

3.33

5.00

21

32

7.50

10.00

5.00

6.67

29

40

7.50

10.00

5.00

6.67

36

50

7.50

10.00

5.00

6.67

42


7.50

10.00

5.00

6.67

48

63

7.50

10.00

5.00

6.67
